Bi-fold Hinge

These Cabinet hinges are designed for use in conjunction with corner cabinets having bi-fold doors.

The hinge boss of the 60 degree bi-fold hinge should be fixed to the same door as the hinge boss of the 170 degree or 155 degree hinge fitted to the cabinet side.

For 19mm thick cabinet doors it is recommended using a mounting plate for 15mm cabinet sides (3mm Spacing).
